S55C Linear Ball Screw Customized Aerospace Ball Screw High Precision

Name: S55C Linear Ball Screw Customized Aerospace Ball Screw High Precision
Brand: SXEGL
Price: 7 USD

Wholesale S55C Linear Ball Screw Customized Aerospace Ball Screw High Precision from china suppliers

Brand Name : SXEGL

Model Number : SFU

Certification : CE/FCC/EPA/ROSH/ISO

Place of Origin : China

MOQ : 1

Packaging Details : Carton

Delivery Time : Small orders usually takes 3-7 days,big order usually 20-35 days, depending on orders quantity and whether are standard size.

Payment Terms : Visa /Mastercard/PayPal/Apple Pay/Google Pay

Supply Ability : All products have passed CE certification and comply with EU RoHS environmental standards

Price : $7-$50

manufacturing process : Rolled Thread

Length : 10-160mm

Name : Linear Ball Screw

material : S55C,SCM420H

Nut type : Single Nut$ Double Nut

Application : 3D Printer/CNC Machine

core component : Engine, Bearing, motor, Pressure vessel

Contact Now

High Performance Linear Ball Screw Transmission Machinery

SEXGL ground ball screws deliver unparalleled accuracy and durability in high-precision automation systems, trusted by global leaders like BYD (EV powertrain assembly) and BOE (LCD panel cutting robots) across North America, Europe, Southeast Asia, and South Korea.As a core transmission component for CNC machine tools, precision instruments, and automation equipment, ball screws achieve high-precision linear motion through a rolling friction pair design: precision balls fill the helical raceways between the screw shaft and nut, converting traditional sliding friction into point/line contact rolling friction with a friction coefficient as low as 0.0015–0.002. This enables positioning accuracy of ±0.001mm over 300mm and repeat positioning accuracy of ±0.0005mm, ensuring micron-level precise displacement for moving components such as machine tool worktables and tool holders. These capabilities meet the stringent requirements of high-precision machining scenarios in aerospace, optical components, and other industries.

															Unit:mm
	Model no.	d	Lead	Bead diameter	(Nut size)									Dynamic Rating Load Ca	Static Rated Load Coa
	Model no.	d	Lead	Bead diameter	D	A	B	L	W	H	X	Q	n	Dynamic Rating Load Ca	Static Rated Load Coa
☆	SFUR1204-3	12	4	2.5	24	40	10	40	32	30	4.5	M6×1	1×3	451	709
	SFUR1604-3	16	4	2.381	28	48	10	36	38	40	5.5	M6×1	1×3	488	940
☆ ☆ ☆ ☆ ☆	SFUR1605-3		5	3.175	28	48	10	42	38	40	5.5	M6×1	1×3	666	1143
	SFUR1605-4		5	3.175	28	48	10	50	38	40	5.5	M6×1	1×4	888	1525
	SFUR1610-3		10	3.175	28	48	10	57	38	40	5.5	M6×1	1×3	716	1232
	SFUR2004-3	20	4	2.381	36	58	10	42	47	44	6.6	M6×1	1×3	541	1187
	SFUR2005-3		5	3.175	36	58	10	42	47	44	6.6	M6×1	1×3	749	1495
	SFUR2005-4		5	3.175	36	58	10	51	47	44	6.6	M6×1	1×4	999	1994
	SFUR2504-3	25	4	2.381	40	62	10	42	51	48	6.6	M6×1	1×3	605	1534
	SFUR2505-3		5	3.175	40	62	10	42	51	48	6.6	M6×1	1×3	839	1935
	SFUR2505-4		5	3.175	40	62	10	51	51	48	6.6	M6×1	1×4	1119	2581
	SFUR2510-3		10	4.762	40	62	10	70	51	48	6.6	M6×1	1×3	1427	2771
	SFUR2510-4		10	4.762	40	62	12	85	51	48	6.6	M6×1	1×4	1903	3695
	SFUR3205-4	32	5	3.175	50	80	12	52	65	62	6	M6×1	1×4	1264	3402
	SFUR3210-3		10	6.35	50	80	12	74	65	62	6	M6×1	1×3	2319	4575
	SFUR3210-4		10	6.35	50	80	12	90	65	62	6	M6×1	1×4	3092	6101
	SFUR4005-4	40	5	3.175	63	93	14	55	78	70	6	M8×1	1×4	1407	4341
	SFUR4010-3		10	6.35	63	93	14	71	78	70	6	M8×1	1×3	2610	5834
	SFUR4010-4		10	6.35	63	93	14	93	78	70	9	M8×1	1×4	3480	7779
	SFUR5010-4	50	10	6.35	75	110	16	93	93	85	11	M8×1	1×4	3898	10325
	SFUR6310-4	63	10	6.35	90	125	18	98	108	95	11	M8×1	1×4	4401	13611
	SFUR6320-4	63	20	9.525	95	135	20	149	115	100	13.5	M8×1	1×4	7404	19008
	SFUR8010-4	80	10	6.35	105	145	20	98	125	110	13.5	M8×1	1×4	4900	17366
	SFUR8020-4	80	20	9.525	125	165	25	154	145	130	13.5	M8×1	1×4	8403	25345
Note: Those marked with ☆ can produce left-hand thread.
